Chassis / Cooling - High Temperature / Cooling Service Procedures / DA-RM-04L001-01-002 - Remove/Install Hose - Header tank - Engine

Preparation work

1.	DA-RM-01A001-00-001 - Secure/Lift vehicle on platform
2.	DA-RM-03A075-04-001 - Remove/Install floor panel - Front
3.	DA-RM-01A004-02-001 - Remove/Install floor panel - Engine
4.	DA-RM-02A051-08-001 - Remove/Install panel - Service Cover
5.	DA-RM-04L001-00-001 - Drain/Fill fluid - Coolant
6.	DA-RM-01A005-02-001 - Remove/Install service hatch - Bulkhead
7.	DA-RM-04B005-01-001 - Remove/Install wheel - Rear
8.	DA-RM-03A076-02-001 - Remove/Install wheel arch liner - Rear
9.	DA-RM-03A075-05-002 - Remove/Install floor panel - Rear extension
10.	DA-RM-02A051-03-004 - Remove/Install panel - Side duct finisher
11.	DA-RM-02A051-03-003 - Remove/Install panel - Dirty air duct
12.	DA-RM-02A051-03-002 - Remove/Install bodyside - Lower
13.	DA-RM-02A051-03-005 - Remove/Install panel - Aero bridge
14.	Care Point: Detach from fuel filler bowl only. DA-RM-04K001-02-001 - Remove/Install fuel filler neck
15.	DA-RM-02A051-03-001 - Remove/Install bodyside - Upper - Left
16.	DA-RM-05F002-03-001 - Remove/Install water charge air cooler (WCAC)

WARNING!
Possible fluid spills from vehicle systems during repairs or maintenance. Risk of thermal incidents, slip hazards, corrosion of electrical components, failure of electrical or mechanical components or unwanted odours. Always limit fluid spills and fully clean the spilled fluid after repairs or maintenance.
