| 1. | Check the tyre pressures when they are at ambient temperature. The correct tyre pressures are shown in the table below.
Front
| Rear
|
2.0 bar
| 2.0 bar
|
| |
| 2. | Start the engine.
| |
| 3. | Set the handling mode to Normal for a minimum of 30 seconds.
| |
| 4. | Set the handling mode to Track for a minimum of 30 seconds.
| |
| 5. | Set the handling mode to Normal for a minimum of 30 seconds.
| |
| 6. | Stop the engine.
| |
| | | Care Point: | The fuel tank must be half full. This weighs approximately 26.5kg. If the fuel tank is not half full, you must adjust the quantity of ballast that you add.
|
| Care Point: | Before you add ballast, drive the vehicle in the workshop. Make sure that the suspension has become stable.
|
| |
| 7. | Put the vehicle on the wheel alignment ramp.
| |
| 8. | Add ballast to the areas shown in the table below:
Driver seat
| Driver side floor
| Passenger seat
| Passenger side floor
|
25kg
| 12.5kg
| 25kg
| 12.5kg
|
| |
