Pin
Interior / Interior Systems / Driver Mirror / DA-WD-N00105-01 - Electrochromatic Rear View Mirror and Rain Light Sensor

Pos No
Name
1
Facia Tweeter Centre High Line - Negative
2
Facia Tweeter Centre High Line - Positive
3
Spare
4
Spare
5
Spare
6
Spare
7
Spare
8
Spare
9
Spare
10
Reverse Light
11

12

13
DBE Waterfall Light
14
Spare
15
Body LIN Rain/Solar/Humidity Sensor
16
Immobiliser LED Drive
17
Spare
18
Spare
19
Spare
20
Spare


   Note
