Electrical / Electrical Systems / Steering Column Module / DA-WD-M00208-01 - MRM

Pos No
Name
1
Driver Airbag Primary-
2
Driver Airbag Primary+
3
Driver Airbag Secondary-
4
Driver Airbag Secondary+
5
Knee Airbag Driver -
6
Knee Airbag Driver +
7
Front Airbag Passenger Stage 1 -
8
Front Airbag Passenger Stage 1 +
9
Front Airbag Passenger Stage 2 -
10
Front Airbag Passenger Stage 2 +
11
Knee Airbag Passenger -
12
Knee Airbag passenger +


   Note
