          DA-WD-N00107-01 - Seats
  Customer Service
Pin
Interior / Interior Systems / Seat Assembly / DA-WD-N00107-01 - Seats

Pos No
Name
1
Power feed
2
Ignition Switch (KL15)C
3
-
4
CAN low
5
CAN high
6
-
7
Ground
8
-
9
Buckle switch driver
10
Buckle switch driver ground
11
-
12
-
13
-
14
-


   Note
